N1 type

Промышленные маркираторы, граверы - оптовые и розничные поставки

N1 type

Артикул: 18 Бренд: King Rabbit
По запросу


  1. Forward direction and reverse direction paper feed
  2. Emergency stop and free setting original point
  3. Maximum speed of 500mm/s
  4. Cutting speed and cutting pressure with memorial storage
  5. Double photoelectric reset and without any collision
  6. Perfect output and without any saw tooth at high speed
  7. Using the most advance subdivision circuit and having low noise
  8. Using switching power supply and its operation won't be influenced by voltage change
  9. Circuit uses low power consumption and doesn’t need fan for  heat radiation so as to ensure long and reliable operation

Type

HX-720N

HX-800N

HX-960N

HX-1120N

HX-1360N

HX-1780N

Maximum paper
feed width

720mm (28.4")

800mm
(31.5")

960mm
 (37.8")

1120mm
 (44.1")

1360mm
(53.6")

1780mm
(70.1'')

Real cutting range

630mm(24.8")
*limitless length

720mm(27.6")
*limitless length

860m(33.9")
*limitless length

1010m(39.8")
*limitless length

1250m(49.2")
*limitless length

1680m(70.1")
*limitless length

Cutting speed

25mm/s-500mm/s(0.98"/s-19.7"/s)

Cutter pressure

25-500g Grade 16-32

English LCD

With

Mechanical
Resolution

0.0254 mm/step(0.001"/step)

Blade  Type

Swivel Standard blade (Compatible with Roland blade)

Interfaces

USB 2.0 and RS232 serial interface

Commands/
Language

HP-GL / DMPL compatible

Bracket

 With
